ELITE 70S-6 SOLID MIG WIRE – CWB APPROVED

Class: ER70S-6

AWS: A5.18

Conforms to Certification: AWS A5.18           ASME SFA A5.18

Weld Process Used for MIG (GMAW)

AWS Chemical Composition Requirements
C = 0.06 – 0.15	Ni = 0.15 max
Mn = 1.40 – 1.85	Cr = 0.15 max
Si = 0.80 – 1.15	Mo = 0.15 max
P = 0.025 max	V = 0.03 max
S = 0.035 max	Cu = 0.50 max

Available Sizes:
.035 x 44 LBS SPOOL & 550 LBS DRUMS
.045 x 44 LBS SPOOL & 550 LBS DRUMS

Application
Type ER70S-6 is a wire with higher levels of Deoxidizers welding of steels with moderate amounts of scale or rust. (Mn & Si) compared to other carbon steel wires. This wire is suitable for welding of steels with moderate amounts of scale or rust.

For Mig welding use 25% CO2 + 75% Ar .

Deposited Chemical Composition % (Typical)
C = 0.09	P = 0.012	Si = 0.95
Mn = 1.65	S = 0.018	Cu = 0.35

Deposited All Weld Metal Properties % (As Welded)
Tensile Strength	78,000 psi
Yield Strength	65,500 psi
Elongation	24%

Deposited Charpy-V-Notch Impact Properties %
45 ft. lbs. (at -20ºF)

Recommended Welding Parameters (GMAW “Mig Process”)
	Wire Diameter	Volts	Amps	IPM
Short Arc Welding	.030	16 – 18	75 – 125	176 – 324
	.035	15 – 18	100 – 160	132 – 228
	.045	17 – 18	100 – 120	149 – 208
Spray Arc Welding	.030	26 – 28	200	560
	.035	27 – 29	250	504
	.045	28 – 31	265	336
	.052	29 – 31	300 – 340	280 – 350
	1/16	30 – 36	350 – 400	220 – 280
